Network graph suite

Visualize BIM relationships with no canvas limits

Turn IFC and CSV exports into explorable system, spatial, and property graphs. Zoom, pan, fit-to-extent, or capture high-res snapshots without being boxed into a fixed viewport.

Launch a graph Start with IFC
Archicad Archicad
Revit Revit
IFC IFC
Deep parsing IFC spatial, type, property set, and system relationships.
CSV aware Revit and Archicad auto-detect extra attributes for richer graphs.
Viewer tools Fit to extent, smart zoom, and one-click PNG captures.

About These Tools

Built for AEC teams that need to see relationships, not rows. Drop an IFC or CSV and the viewers will auto-build element, spatial, system, and attribute graphs that you can freely pan, zoom, and export.

1
Export Data
Export your model data as CSV/IFC from your BIM software using ReUniXchange or ArchUniXchange
2
Choose Tool
Select the appropriate visualization tool below
3
Upload CSV/IFC
Import your CSV/IFC data into the selected tool
4
Visualize
Explore your interactive network diagram
Archicad

ArchiCAD Network Diagram

ArchiCAD CSV explorer that auto-detects materials, zones, and classifications while keeping the graph free-form for deep pans and exports.

  • ArchiCAD element relationship mapping
  • Zone and space connectivity analysis
  • Building component hierarchy visualization
  • Layer and classification grouping
  • Material and property connections
Launch ArchiCAD Tool
Revit

Revit Network Diagram

Optimized for Revit CSV exports with family, system, level, and auto-detected attribute networks plus fit-to-extent and image capture controls.

  • Family and type relationship mapping
  • MEP system connectivity analysis
  • Parameter dependency visualization
  • Workset and phase grouping
  • Level and grid associations
Launch Revit Tool
IFC

Universal IFC Network Diagram

IFC viewer that builds element, spatial, system, and property-set graphs from any compliant model—no canvas limits, just pure BIM relationships.

  • IFC schema compliance
  • Universal BIM data support
  • Cross-platform compatibility
  • Standard entity relationships
  • Interoperability analysis
Launch IFC Tool
